. CPU Support

Socket: LGA1700

Supports: Intel® 14th, 13th, and 12th Generation Core™, Pentium® Gold, and Celeron® processors.

L3 Cache: Varies by CPU.

Chipset: Intel® Z790 Express Chipset.

2. Memory Support

DDR4 Memory Speeds: Up to 5333 MT/s (O.C.) with support for various other speeds (e.g., 3200/3000/2933/2666/2400/2133 MT/s).

Capacity: Up to 128 GB (4x DIMMs, 32 GB per DIMM).

Dual-channel architecture.

Supports XMP (Extreme Memory Profile) for easier overclocking.

Supports ECC Un-buffered DIMM (in non-ECC mode) and non-ECC Un-buffered DIMMs.

3. Integrated Graphics (depending on CPU support)

DisplayPort: Supports up to 4096x2304 @ 60 Hz (DP 1.2, HDCP 2.3).

HDMI 2.1: Supports up to 4096x2160 @ 60 Hz (HDCP 2.3, native HDMI 2.1 TMDS).

4. Audio

Realtek® Audio CODEC.

Supports up to 7.1-channel HD audio with S/PDIF out.

5. LAN

Realtek® 2.5GbE LAN (2.5 Gbps/1 Gbps/100 Mbps).

6. Expansion Slots

1 x PCIe 4.0 x16 (full x16 support, reserved for graphics cards or NVMe SSD).

2 x PCIe 3.0 x1 slots (for expansion cards).

7. Storage

M.2 Slots:

1 x M.2 (PCIe 4.0 x4) connected to the CPU.

2 x M.2 (PCIe 4.0 x4) connected to the chipset.

SATA: 4 x SATA 6Gb/s ports with RAID 0, 1, 5, 10 support for both NVMe and SATA.

8. USB Ports

USB 3.2 Gen 2:

1x USB Type-C® (internal header).

1x USB 3.2 Gen 2 Type-A (rear panel).

USB 3.2 Gen 1:

2x USB 3.2 Gen 1 (rear).

2x USB 3.2 Gen 1 (internal header).

USB 2.0/1.1:

1x USB 2.0/1.1 (rear).

8x USB 2.0/1.1 (rear and internal headers).

9. Internal I/O Connectors

Power connectors: 24-pin ATX, 8-pin ATX 12V.

Cooling: CPU fan, water pump, system fan headers, hybrid fan headers, and fan stop support.

RGB: 2x addressable LED strip headers, 2x RGB LED strip headers.

Other connectors: Front audio, S/PDIF, USB 3.2, USB 2.0, TPM, serial port, and Q-Flash Plus button.

10. Back Panel Connectors

USB: 1x USB 3.2 Gen 2 Type-A, 2x USB 3.2 Gen 1, 5x USB 2.0/1.1.

Display: 1x DisplayPort, 1x HDMI.

Audio: 6x audio jacks.

Networking: 1x RJ-45 (2.5GbE).

11. BIOS

256 Mbit flash.

AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0.

Features: Q-Flash Plus, Smart Backup.

12. Unique Features

Gigabyte Control Center (GCC) support for system management.

Q-Flash, allows BIOS updates without CPU, RAM, or GPU.

13. Software and OS Support

Norton® Internet Security (OEM).

Windows 11 and Windows 10 64-bit support.

14. Form Factor

ATX (30.5cm x 24.4cm).

This motherboard is a well-rounded choice for users looking for a powerful yet flexible platform that supports both current and next-gen Intel processors and DDR4 memory.
