CPU Compatibility

AMD Socket AM5

Supports AMD Ryzen™ 9000, 8000, and 7000 Series Desktop Processors

Chipset

AMD B850 Chipset

Memory

4 x DIMM slots, up to 256GB DDR5

Supports speeds up to 8000+MT/s (OC) with Ryzen 9000, 8000 & 7000 Series

Dual-channel memory architecture

AMD Extended Profiles for Overclocking (EXPO™)

ASUS Enhanced Memory Profile (AEMP)

Graphics Output

1 x DisplayPort (max. 8K@30Hz)

1 x HDMI (max. 4K@60Hz)

1 x USB4 (40Gbps) Type-C with DisplayPort 1.4a (max. 4K@60Hz)

Expansion Slots

For Ryzen 9000 & 7000 Series:

1 x PCIe 5.0 x16 (Q-Release Slim, supports x16/x8 modes)

For Ryzen 8000 Series:

1 x PCIe 5.0 x16 (Q-Release Slim, supports PCIe 4.0 x8/x4 mode)

B850 Chipset:

1 x PCIe 4.0 x16 (supports x4 mode)

Storage

M.2 Slots (Total 5):

1 x PCIe 5.0 x4 (Ryzen 9000/7000)

2 x PCIe 5.0 x4 (Ryzen 9000/7000)

1 x PCIe 4.0 x4 (B850 Chipset)

1 x PCIe 4.0 x4 (B850 Chipset)

SATA Ports:

4 x SATA 6Gb/s (ASMedia ASM1061 Controller)

RAID Support:

Ryzen 9000: RAID 0/1/5/10

Ryzen 8000: RAID 0/1

Ryzen 7000: RAID 0/1/10

Networking

Wired:

1 x Realtek 5Gb Ethernet with ASUS LANGuard

Wireless:

Wi-Fi 7 (802.11be), 2x2, supports 2.4/5/6GHz bands

Bluetooth 5.4

USB Ports

Rear I/O (Total 12):

1 x USB4 (40Gbps, Type-C)

1 x USB 20Gbps (Type-C, up to 30W PD/PPS Fast-charge)

6 x USB 10Gbps (Type-A)

4 x USB 2.0 (Type-A)

Front I/O (Total 7):

1 x USB 10Gbps (Type-C)

1 x USB 5Gbps header (supports 2 x USB 5Gbps)

2 x USB 2.0 headers (supports 4 x USB 2.0)

Audio

ROG SupremeFX 7.1 Surround Sound (ALC4080 Codec)

Savitech SV3H712 AMP

120 dB SNR stereo playback, 110 dB SNR recording

Supports up to 32-bit/384 kHz playback

Cooling & Power

1 x 24-pin ATX Power Connector

2 x 8-pin CPU Power Connectors

1 x 4-pin CPU Fan Header

1 x 4-pin CPU OPT Fan Header

1 x 4-pin AIO Pump Header

5 x 4-pin Chassis Fan Headers

Back Panel I/O Ports

1 x USB4 (40Gbps, Type-C)

1 x USB 20Gbps (Type-C, 30W PD Fast-Charge)

6 x USB 10Gbps (Type-A)

4 x USB 2.0 (Type-A)

1 x DisplayPort

1 x HDMI

1 x Wi-Fi Module

1 x 5Gb Ethernet Port

2 x Gold-Plated Audio Jacks

1 x Optical S/PDIF Out

1 x BIOS FlashBack™ Button

1 x Clear CMOS Button

Special Features

Q-Design: M.2 Q-Latch, PCIe Slot Q-Release Slim, Q-Code, Q-LED, Q-Slot

EZ DIY: BIOS FlashBack™, Clear CMOS, SafeSlot, SafeDIMM

Aura Sync RGB: Addressable Gen 2 Headers

ROG Exclusive Software: CPU-Z, Dolby Atmos

ASUS Software: Armoury Crate, Fan Xpert 4, HWiNFO, USB Wattage Watcher

Form Factor

ATX (30.5 cm x 24.4 cm)
