CPU Compatibility

Socket AM5: Compatible with AMD Ryzen™ 9000, 8000, and 7000 Series Desktop Processors.

Supports CPUs up to 120W.

Chipset

AMD A620 Chipset: Provides a balance between performance and features.

Memory

2 x DIMM slots: Maximum of 96GB.

DDR5 Memory: Supports speeds from 5800 MHz up to 7200 MHz (overclocked).

Dual Channel Memory Architecture.

AMD Extended Profiles for Overclocking (EXPO™).

On-Die ECC Function: For improved stability.

Graphics

1 x DisplayPort: Up to 8K@60Hz.

1 x HDMI™: Up to 4K@60Hz.

1 x VGA port.

Expansion Slots

1 x PCIe 4.0 x16 slot: For graphics cards (supports x16 mode for Ryzen™ 9000 & 7000 Series, x8/x4 mode for Ryzen™ 8000 Series).

2 x PCIe 3.0 x1 slots: For additional expansion cards.

Storage

1 x M.2 slot: PCIe 4.0 x4 mode (supports 2242/2260/2280).

4 x SATA 6Gb/s ports.

AMD RAIDXpert2 Technology: Supports PCIe and SATA RAID 0/1/10.

Ethernet

1 x Realtek 1Gb Ethernet: Reliable network connectivity.

USB Ports

Rear USB Ports: 4 x USB 3.2 Gen 1 (5G) ports, 4 x USB 2.0 ports.

Front USB Ports: 1 x USB 3.2 Gen 1 (5G) header (supports 2 additional ports), 2 x USB 2.0 headers (supports 4 additional ports).

Audio

Realtek 7.1 Surround Sound High Definition Audio CODEC.

Supports up to 24-Bit/192 kHz playback.

Features: Audio Shielding, Premium capacitors, Dedicated audio PCB layers.

Back Panel I/O Ports

4 x USB 3.2 Gen 1 (5G) ports.

4 x USB 2.0 ports.

1 x DisplayPort.

1 x VGA port.

1 x HDMI™ port.

1 x Realtek 1Gb Ethernet port.

3 x Audio jacks.

1 x PS/2 Keyboard/Mouse combo port.

Internal I/O Connectors

Fan Headers: 1 x CPU Fan header, 2 x Chassis Fan headers.

Power Connectors: 1 x 24-pin Main Power connector, 1 x 8-pin +12V Power connector.

Storage Connectors: 1 x M.2 slot, 4 x SATA 6Gb/s ports.

USB Headers: 1 x USB 3.2 Gen 1 header, 2 x USB 2.0 headers.

Miscellaneous: 2 x Addressable Gen 2 headers, 1 x Aura RGB header, 1 x Clear CMOS header, etc.

Special Features

ASUS 5X PROTECTION III: Includes DIGI+ VRM, LANGuard, Overvoltage Protection, SafeSlot Core+, Stainless-Steel Back I/O.

ASUS Q-Design: Features Q-DIMM, Q-LED Core, Q-Slot for easier component installation.

ASUS Thermal Solution: Includes an aluminum heatsink design.

Aura Sync: RGB lighting with Addressable Gen 2 headers and Aura RGB header.

Software Features

Armoury Crate: Includes Aura Creator, Aura Sync, Fan Xpert 2+, Power Saving, Two-Way AI Noise Cancellation.

AI Suite 3: TurboV EVO, DIGI+ VRM, PC Cleaner.

ASUS CPU-Z, Norton 360 Deluxe (60 Days Free Trial), WinRAR.

BIOS

256 Mb Flash ROM, UEFI AMI BIOS: Includes ASUS EZ DIY features like CrashFree BIOS 3 and EZ Flash 3.

Manageability

WOL by PME, PXE: For remote management.

Accessories

Cables: 2 x SATA 6Gb/s cables.

Miscellaneous: 1 x I/O Shield, 1 x Screw package for M.2 SSD.

Documentation: 1 x ACC Express Activation Key Card, 1 x User guide.

Operating System

Windows® 11, Windows® 10 64-bit.

Form Factor

Micro-ATX: 8.9 x 8.7 inches (22.6 cm x 22.1 cm).
