CPU

• Supports Intel® Core™ Ultra Processors (Series 2), LGA1851
• Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0

Chipset

• Intel® Z890 Chipset

Memory

• 4 x DIMM slots, max. 192GB, DDR5
• Supports up to 9066+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)
• Dual channel memory architecture

Graphics

• 1 x DisplayPort
• 1 x HDMI™ port
• 1 x Intel® Thunderbolt™ 4 port (USB Type-C®) supports DisplayPort and Thunderbolt™ video outputs
• 1 x USB 20Gbps port (USB Type-C®) supports DisplayPort video output

Expansion Slots

• 1 x PCIe 5.0 x16 slot
• 1 x PCIe 4.0 x16 slot (supports x4 mode)
• 1 x PCIe 4.0 x4 slot
• 2 x PCIe 4.0 x1 slots

Storage

• Supports 4 x M.2 slots and 4 x SATA 6Gb/s ports
• M.2_1 slot (Key M): supports PCIe 5.0 x4 mode
• M.2_2 slot (Key M): supports PCIe 4.0 x4 mode
• M.2_3 slot (Key M): supports PCIe 4.0 x4 mode
• M.2_4 slot (Key M): supports PCIe 4.0 x4 & SATA modes

Ethernet

• 1 x Intel® 2.5Gb Ethernet

Wireless & Bluetooth

• Wi-Fi 7 (802.11be)
• Bluetooth® v5.4

USB

• Rear USB (Total 8 ports)
• 1 x Thunderbolt™ 4 port (USB Type-C®)
• 1 x USB 20Gbps port (USB Type-C®)
• 3 x USB 10Gbps ports (Type-A)
• 3 x USB 5Gbps ports (Type-A)
• Front USB (Total 7 ports)
• 1 x USB 20Gbps connector (supports USB Type-C®)
• 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
• 2 x USB 2.0 headers support 4 additional USB 2.0 ports

Audio

• Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC

Back Panel I/O Ports

• 1 x Thunderbolt™ 4 USB Type-C® port
• 1 x USB 20Gbps port (USB Type-C® with DP Alt mode)
• 3 x USB 10Gbps ports (Type-A)
• 3 x USB 5Gbps ports (Type-A)
• 1 x DisplayPort
• 1 x HDMI™ port
• 1 x Wi-Fi module
• 1 x Intel® 2.5Gb Ethernet port
• 5 x Audio jacks
• 1 x Optical S/PDIF out port
• 1 x BIOS FlashBack™ button

Internal I/O Connectors

See list for details on Fan and Cooling, Power, Storage, USB, Miscellaneous

Special Features

• ASUS TUF PROTECTION
• ASUS Q-Design
• ASUS Thermal Solution
• ASUS EZ DIY
• Aura Sync

Software Features

• ASUS Exclusive Software
• ASUS DriverHub
• ASUS GlideX
• TurboV Core
• TUF GAMING CPU-Z
• DTS Audio Processing
• UEFI BIOS
• Manageability

Accessories

• Cables
• Miscellaneous
• Documentation

Operating System

• Windows 11 (22H2 & later)

Form Factor

• ATX Form Factor
