CPU Support:

Socket: AMD Socket AM5

Supported Processors: AMD Ryzen™ 9000, 8000, and 7000 Series Desktop Processors

Chipset:

Chipset: AMD B650

Memory:

Memory Slots: 4 x DIMM slots

Max Capacity: Up to 192GB DDR5

Supported Memory Speeds (OC): DDR5 7600+(OC) down to 4800, with support for both ECC and Non-ECC, Un-buffered memory

Features: Dual Channel Memory Architecture, AMD Extended Profiles for Overclocking (EXPO™), OptiMem II technology

Graphics:

Outputs:

2 x DisplayPort (up to 8K@60Hz, DP 1.4)

1 x HDMI port (up to 4K@60Hz, HDMI 2.1)

Note: Graphics output depends on the CPU used.

Expansion Slots:

PCIe Slots:

1 x PCIe 4.0 x16 slot (varies by CPU series)

2 x PCIe 4.0 x1 slots

Storage:

M.2 Slots:

2 x M.2 slots supporting PCIe 5.0/4.0 depending on the processor

SATA Ports:

4 x SATA 6Gb/s ports

RAID Support: AMD RAIDXpert2 Technology supports both PCIe and SATA RAID 0/1/10

Networking:

Ethernet: 1 x Realtek 2.5Gb Ethernet with TUF LANGuard

Wireless & Bluetooth: Wi-Fi 6 (802.11 a/b/g/n/ac/ax), Bluetooth® v5.2

USB Connectivity:

Rear I/O Ports (Total 8):

2 x USB 3.2 Gen 2 (10G) ports (1 x Type-A, 1 x Type-C®)

2 x USB 3.2 Gen 1 (5G) Type-A ports

4 x USB 2.0 Type-A ports

Front I/O Ports (Total 7):

1 x USB 3.2 Gen 1 (5G) Type-C® connector

1 x USB 3.2 Gen 1 (5G) header for 2 additional ports

2 x USB 2.0 headers for 4 additional ports

Audio:

Codec: Realtek 7.1 Surround Sound High Definition Audio CODEC

Features: Jack-detection, Multi-streaming, Front Panel Jack-retasking, Audio Shielding, Premium audio capacitors, Dedicated audio PCB layers

Back Panel I/O Ports:

USB:

2 x USB 3.2 Gen 2 (10G) ports (Type-A + Type-C®)

2 x USB 3.2 Gen 1 (5G) ports (Type-A)

4 x USB 2.0 ports (Type-A)

Display Outputs:

2 x DisplayPort

1 x HDMI™ port

Other:

1 x Wi-Fi Module

1 x Realtek 2.5Gb Ethernet port

3 x Audio jacks

1 x BIOS FlashBack™ button

1 x PS/2 Keyboard/Mouse combo port

Internal I/O Connectors:

Fan & Cooling:

1 x 4-pin CPU Fan header

1 x 4-pin CPU OPT Fan header

1 x 4-pin AIO Pump header

2 x 4-pin Chassis Fan headers

Power Connectors:

1 x 24-pin Main Power connector

1 x 8-pin +12V Power connector

1 x 4-pin +12V Power connector

Storage Connectors:

2 x M.2 slots

4 x SATA 6Gb/s ports

USB Connectors:

1 x USB 3.2 Gen 1 (5G) Type-C® connector

1 x USB 3.2 Gen 1 (5G) header for 2 ports

2 x USB 2.0 headers for 4 ports

Miscellaneous Connectors:

3 x Addressable Gen 2 headers

1 x Aura RGB header

1 x Clear CMOS header

1 x COM Port header

1 x Front Panel Audio header (AAFP)

1 x 20-3 pin System Panel header with Chassis intrude function

Special Features:

ASUS TUF PROTECTION: Includes DIGI+ VRM, ESD Guards, TUF LANGuard, Overvoltage Protection, SafeSlot Core+, Stainless-Steel Back I/O

ASUS Q-Design: M.2 Q-Latch, Q-DIMM, Q-LED, Q-Slot

ASUS Thermal Solution: M.2 heatsink, VRM heatsink design

ASUS EZ DIY: BIOS FlashBack™ button, Pre-mounted I/O shield, SafeDIMM

Aura Sync: Aura RGB header, Addressable Gen 2 headers

Software Features:

ASUS Exclusive Software: Armoury Crate, Aura Creator, Aura Sync, Fan Xpert 2+, AI Suite 3, TUF GAMING CPU-Z, DTS Audio Processing, MyASUS, Norton 360 for Gamers (60 Days Free Trial), WinRAR

BIOS Features: ASUS CrashFree BIOS 3, ASUS EZ Flash 3, ASUS UEFI BIOS EZ Mode

Form Factor:

Size: micro-ATX (9.6 inch x 9.6 inch / 24.4 cm x 24.4 cm)
