CPU Support

Socket: AMD Socket AM5

Processors: AMD Ryzen™ 7000 / 8000 / 9000 Series

Chipset

Model: AMD B650

Memory

Type: DDR5

Speed: 5600 - 8000 MT/s (overclocked)

Capacity: Up to 256 GB (64 GB per DIMM)

Architecture: Dual channel

Support: AMD EXPO™ and XMP profiles

Onboard Graphics

Graphics Processor: AMD Radeon™ Graphics

DisplayPort: 1 x DisplayPort (3840x2160@144 Hz)

HDMI: 1 x HDMI (4096x2160@60 Hz)

Audio

Codec: Realtek® Audio CODEC

Channels: 2/4/5.1/7.1

S/PDIF Out: Supported

Networking

LAN: Realtek® 2.5GbE LAN (2.5 Gbps / 1 Gbps / 100 Mbps)

Wi-Fi: Realtek® Wi-Fi 6E RTL8852CE (2.4/5/6 GHz, Bluetooth 5.3)

Expansion Slots

PCIe x16 Slot (CPU):

AMD Ryzen™ 7000 Series: PCIe 4.0 x16

AMD Ryzen™ 8000 Series-Phoenix 1: PCIe 4.0 x8

AMD Ryzen™ 8000 Series-Phoenix 2: PCIe 4.0 x4

PCIe x16 Slot (Chipset): PCIe 4.0 x4

Storage Interfaces

M.2 Connectors:

M2A_CPU: PCIe 5.0 x4/x2 (7000 Series), PCIe 4.0 x4/x2 (8000 Series-Phoenix 1 and 2)

M2B_CPU: PCIe 4.0 x4/x2 (7000 Series and 8000 Series-Phoenix 1), PCIe 4.0 x2 (8000 Series-Phoenix 2)

SATA Connectors: 4 x SATA 6Gb/s

RAID Support: RAID 0, 1, 10

USB Ports

Back Panel:

1 x USB Type-C® (USB 3.2 Gen 2)

2 x USB 3.2 Gen 2 Type-A (red)

4 x USB 2.0/1.1

Internal:

1 x USB Type-C® (USB 3.2 Gen 2x2)

3 x USB 3.2 Gen 1

4 x USB 2.0/1.1

Internal I/O Connectors

Power Connectors:

1 x 24-pin ATX

1 x 8-pin ATX 12V

Fan Connectors:

CPU fan header

CPU fan/water cooling pump header

3 x system fan headers

1 x system fan/water cooling pump header

LED Headers:

2 x addressable LED strip headers

2 x RGB LED strip headers

1 x CPU cooler LED strip/RGB LED strip header

Other Connectors:

2 x M.2 Socket 3

4 x SATA 6Gb/s

Front panel header

Front panel audio header

USB headers

Serial port header

Trusted Platform Module header

Reset button and jumper

Clear CMOS jumper

Back Panel Connectors

Buttons:

Q-Flash Plus button

Antenna Connectors: 2 x SMA connectors (2T2R)

Ports:

1 x DisplayPort

1 x HDMI

1 x USB Type-C® (USB 3.2 Gen 2)

2 x USB 3.2 Gen 2 Type-A (red)

5 x USB 3.2 Gen 1

4 x USB 2.0/1.1

1 x RJ-45 (LAN)

1 x optical S/PDIF Out

2 x audio jacks

BIOS

Flash Memory: 256 Mbit

BIOS Type: AMI UEFI BIOS

Unique Features

GIGABYTE Control Center (GCC)

Q-Flash and Q-Flash Plus support

Operating System

Support: Windows 11 64-bit, Windows 10 64-bit

Form Factor

Size: Micro ATX (24.4cm x 24.4cm)
