CPU Compatibility:

Socket: LGA1700

Supported CPUs:

14th, 13th, and 12th Gen Intel® Core™, Pentium® Gold, and Celeron® processors.

L3 cache varies by CPU.

(Refer to GIGABYTE's CPU support list for specifics.)

Chipset:

Intel® B760 Express Chipset.

Memory:

Type: DDR4.

Maximum Capacity: Up to 128GB (32GB per DIMM).

Speeds:

Standard: 2133–3200 MT/s.

Overclocked: Up to 5333 MT/s.

Slots: 4 x DIMM.

Features:

Dual-channel architecture.

Supports ECC (non-ECC mode) and non-ECC un-buffered modules.

XMP support for performance tuning.

Graphics:

Integrated Intel® Graphics support (dependent on CPU):

HDMI 2.1: Up to 4096x2160 @ 60Hz.

DisplayPort 1.2: Up to 4096x2304 @ 60Hz.

Triple-display support.

Storage:

M.2 Slots:

1 x PCIe 4.0 x4 (CPU).

1 x PCIe 4.0 x4 (Chipset).

SATA: 4 x SATA 6Gb/s.

RAID Support: 0, 1, 5, 10.

Expansion Slots:

PCIe 4.0 x16: 1 slot (GPU or NVMe SSD).

PCIe 3.0 x1: 2 slots.

Connectivity:

LAN: Realtek® 2.5GbE LAN.

Wi-Fi:

PCB rev. 1.0: AMD Wi-Fi 6E RZ608.

PCB rev. 1.1/1.2/1.3: Intel® Wi-Fi 6E (AX210/AX211) or Realtek® Wi-Fi 6E.

Supports Bluetooth 5.2/5.3 (varies by revision).

USB Ports:

Rear Panel:

1 x USB 3.2 Gen 2 Type-C.

3 x USB 3.2 Gen 1.

2 x USB 2.0.

Internal Headers:

1 x USB 3.2 Gen 1.

4 x USB 2.0.

Audio:

Realtek® Audio Codec.

Configurable for up to 7.1-channel output.

S/PDIF Out support.

Unique Features:

Q-Flash Plus: Update BIOS without CPU or RAM.

PCIe EZ-Latch: Simplifies GPU installation/removal.

Fan and Thermal Monitoring: Advanced fan and voltage control options.

Form Factor:

Micro-ATX (24.4cm x 24.4cm).
