Intel® Core™ Ultra 5 225F SpecificationsGeneral Information

• Product Collection: Intel® Core™ Ultra Processors (Series 2)
• Code Name: Arrow Lake
• Segment: Desktop
• Processor Number: 225F
• Overall Peak TOPS (Int8): 19

Core & Thread Configuration

• Total Cores: 10 (6 Performance + 4 Efficient)
• Total Threads: 10
• Performance-Core Base Frequency: 3.3 GHz
• Efficient-Core Base Frequency: 2.7 GHz
• Max Turbo Frequency: 4.9 GHz
• Performance-Core Max Turbo Frequency: 4.9 GHz
• Efficient-Core Max Turbo Frequency: 4.4 GHz

Cache & Power

• Intel® Smart Cache: 20 MB
• Total L2 Cache: 22 MB
• Base Power: 65 W
• Maximum Turbo Power: 121 W

Memory

• Max Memory Size: 256 GB
• Memory Type: Up to DDR5 6400 MT/s
• Max Memory Channels: 2

AI & NPU

• Intel® AI Boost NPU
• NPU Peak TOPS (Int8): 13
• Sparsity Support: Yes
• Windows Studio Effects Support: Yes
• Supported AI Frameworks: OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN

Expansion & Connectivity

• DMI Revision: 4
• Max DMI Lanes: 8
• Intel® Thunderbolt™ 4: Yes
• Scalability: 1S Only
• PCI Express Revision: 5.0 and 4.0
• PCI Express Configurations: Up to 1x16+2x4, 2x8+2x4, 1x8+4x4
• Max PCI Express Lanes: 24

Package & Thermal

• Socket: FCLGA1851
• Thermal Solution: PCG 2022C
• Max Operating Temperature: 105°C

Advanced Technologies

• Intel® Deep Learning Boost (Intel® DL Boost)
• Intel® Thread Director
• Intel® Speed Shift Technology
• Intel® Turbo Boost Technology 2.0
• Intel® Gaussian & Neural Accelerator 3.5
• Intel® Volume Management Device (VMD)
• Instruction Set: 64-bit
• Supported Extensions: Intel® SSE4.1, SSE4.2, AVX2
