Intel® Core™ Ultra 5 225 Processor – Specifications

General Information:

• Series: Intel® Core™ Ultra Processors (Series 2)
• Codename: Arrow Lake
• Segment: Desktop

CPU Specifications:

• Cores: 10 (6 Performance + 4 Efficient)
• Threads: 10
• Base Clock:
• Performance Cores: 3.3 GHz
• Efficient Cores: 2.7 GHz
• Max Turbo Frequency:
• Performance Cores: 4.9 GHz
• Efficient Cores: 4.4 GHz
• Cache:
• L2 Cache: 22 MB
• Smart Cache: 20 MB
• Power Consumption:
• Base Power: 65W
• Max Turbo Power: 121W
• AI Acceleration: Intel® Deep Learning Boost (Intel® DL Boost)
• AI Frameworks Supported: OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
• Manufacturing Process: TSMC N3B

Memory Specifications:

• Max Memory Capacity: 256 GB
• Memory Type: Up to DDR5-6400 MT/s
• Memory Channels: 2

Graphics Specifications:

• GPU: Intel® Graphics
• Xe-Cores: 2
• Base Frequency: 300 MHz
• Max Dynamic Frequency: 1.8 GHz
• GPU AI Performance: 4 TOPS (Int8)
• Max Display Support: 4
• Max Resolutions:
• HDMI 2.1: 4K @ 60Hz, 8K @ 60Hz
• DisplayPort 2.1: 8K @ 60Hz
• eDP 1.4b: 4K @ 60Hz
• API Support: DirectX 12, OpenGL 4.5, OpenCL 3
• Intel® Quick Sync Video: Yes
• Deep Learning Boost on GPU: Yes

NPU Specifications:

• NPU Name: Intel® AI Boost
• NPU AI Performance: 13 TOPS (Int8)
• Sparsity Support: Yes
• Windows Studio Effects Support: Yes
• AI Frameworks Supported: OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN

Expansion & Connectivity:

• DMI Revision: 4
• DMI Lanes: 8
• Thunderbolt™ 4: Yes
• PCIe Revision: 5.0 and 4.0
• PCIe Configurations: Up to 1x16+2x4, 2x8+2x4, 1x8+4x4
• PCIe Lanes: 24

Socket & Thermal Details:

• Socket: FCLGA1851
• Thermal Solution: PCG 2022C
• Max Operating Temperature: 105°C
