• Family: Ryzen
• Series: Ryzen 9000 Series
• Form Factor: Desktop, Boxed Processor
• Market Segment: Enthusiast Desktop
• Architecture: Zen 5
• Former Codename: Granite Ridge AM5
• CPU Cores: 8
• Threads: 16
• Base Clock: 4.7 GHz
• Max Boost Clock: Up to 5.2 GHz
• L1 Cache: 640 KB
• L2 Cache: 8 MB
• L3 Cache: 96 MB
• Default TDP: 120W
• Fabrication Process:
• CPU Cores: TSMC 4nm FinFET
• I/O Die: TSMC 6nm FinFET
• Unlocked for Overclocking: Yes
• AMD EXPO Memory Overclocking Technology: Yes
• Precision Boost Overdrive: Yes
• Curve Optimizer Voltage Offsets: Yes
• AMD Ryzen Master Support: Yes
• CPU Socket: AM5
• Supported Chipsets: A620, X670E, X670, B650E, B650, X870E, X870, B840, B850
• CPU Boost Technology: Precision Boost 2
• Instruction Set: x86-64
• Supported Extensions: AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
• Thermal Solution (PIB): Not Included
• Recommended Cooling: Liquid cooling recommended for optimal performance
• Max Operating Temperature (Tjmax): 95°C
• Launch Date: November 7, 2024

Memory & Storage

• System Memory Type: DDR5
• Memory Channels: 2
• Max Memory Capacity: 192 GB
• Memory Type: UDIMM
• Max Memory Speed:
• 2x1R: DDR5-5600
• 2x2R: DDR5-5600
• 4x1R: DDR5-3600
• 4x2R: DDR5-3600
• ECC Support: Yes (Requires motherboard support)
• PCI Express Version: PCIe 5.0
• Native PCIe Lanes: 28 Total, 24 Usable
• NVMe Support: Boot, RAID0, RAID1, RAID5, RAID10

Graphics

• Graphics Model: AMD Radeon Graphics
• Graphics Core Count: 2
• Graphics Frequency: 2200 MHz
• USB Type-C DisplayPort Alternate Mode: Yes

Connectivity

• Native USB 3.2 Gen 2 (10Gbps): 4 Ports
• Native USB 2.0 (480Mbps): 1 Port

OS Support

• Windows 11 64-bit
• Windows 10 64-bit
• RHEL x86 64-bit
• Ubuntu x86 64-bit
