Model: Viewport-Mini

Type: Mini Tower

Color: Black, White

Material: SPCC (Body), Steel + Tempered Glass (Front Panel)

Steel Thickness: 0.5mm

Motherboard Support: Micro ATX / Mini-ITX

Internal Dimensions: 212 x 420 x 360mm (W x H x D)

Overall Dimensions: 212 x 437 x 377.5mm (W x H x D)

Drive Bays:

3.5” Drive Bays: 1 (supports 3.5” or 2.5”)

2.5” Drive Bays: 3 (2 x 2.5” + 1 x 2.5”/3.5”)

Expansion Slots: 4

GPU Clearance: Up to 355mm (without side radiator)

CPU Cooler Clearance: Up to 165mm

Air Cooling:

Top: 120mm x 2 or 140mm x 2 (Max.)

Side: 120mm x 2 (Max.)

PSU Shroud: 120mm x 2 (Max.)

Rear: 120mm x 1 (Max.)

Liquid Cooling:

Top: 240/280mm Radiator (Optional)

Rear: 120mm Radiator (Optional)

I/O Ports:

USB3.0 x 1

USB2.0 x 2

HD Audio & Mic

Internal Cable Management Depth: 24.5mm

Power Supply: ATX PSU (up to 205mm), optional
