Exterior Color: Black

Materials: Steel, Plastic, Tempered Glass (Left Side Panel)

Dimensions:

390 x 203.5 x 430mm (including protrusions)

377 x 203.5 x 410mm (excluding protrusions)

Motherboard Support: ITX / Micro ATX

Expansion Slots: 4

Drive Bays:

I/O Panel:

1x USB 3.2 Gen 1 Type-A

1x USB 3.2 Gen 1 Type-C

1x 3.5mm Combo Audio In/Out

Pre-installed Fans: 3x 120mm CF120 ARGB (Front)

Fan Support:

Front: 3x 120mm

Top: 2x 120mm / 2x 140mm

Rear: 1x 120mm

Radiator Support:

Front: 120mm / 240mm

Top: 120mm / 140mm / 240mm / 280mm

Rear: 120mm

Clearance:

CPU Cooler: 163.5mm

PSU: 160mm

GPU: 365mm (without front fans & radiator)

Cable Routing: 18.5mm

Dust Filters: Top / Bottom / Front

Power Supply Support: ATX

Series: Elite Series

Size: Mini Tower

Cooler Master Elite NEX 700W PSU (MPW-7001-ACBK-P):

ATX Version: ATX 12V Ver. 2.41

PFC: Active PFC

Input Voltage: 200-240V

Input Current: 4.5A

Input Frequency: 50-60Hz

Dimensions: 140 x 150 x 86 mm

Fan Size: 120mm

Fan Bearing: Sleeve Fan

Efficiency: ≥ 75% @ Typical Load

ErP 2014 Lot 3: Yes

Operating Temperature: 0-40°C

Power Good Signal: 100 - 500 ms

Hold Up Time: ≥10ms at 100% load

MTBF: >100,000 Hours

Protections: OVP / OPP / SCP / UVP / OTP / Inrush Protection

Regulatory: TUV, CE, CCC, EAC, UKCA

Connectors:

1x ATX 24 Pin

1x EPS 4+4 Pin

5x SATA Connectors

3x Peripheral 4 Pin

2x PCI-e 6+2 Pin

Modular: Non Modular

80 Plus Efficiency: None 80 PLUS

Watts: 700W
